Control Functions 4-32
Compression damping force
Turn the compression damping force
adjusting screw (use 2.5mm allen wrench) in
direction ⓐ to increase the compression
damping force and thereby harden the
damping, and in direction ⓑ to decrease the
compression damping force and thereby
soften the damping.
1. Compression damping force adjusting screw
·Suspension compone nts become hot
during operation. Never touch the
compression damping force adjusting
screw, the rebound damping force
adjusting screw or the oil reservoir with
your bare hand or skin until suspension
components have cooled.
·
Always adjust the shock absorbe r
assemblies on the left and right side to
the same setting. Uneven adjustment can
cause poor handling and loss of stability,
which could lead to an accident.
