8-42 Periodic Maintenance and Adjustment
1. Arrow mark
1. Tapered nut
2. Lower the vehicle so that the wheel is on
the ground.
3. Tighten the wheel nuts to the specified
torque.
Wheel nut torque:
Front：49.7 ft·lbs (70Nm, 7.0 m·kgf)
Rear：49.7 ft·lbs (70Nm, 7.0 m·kgf)
To Next Page
