Collamat 3600 - Test Software

Test software
When the Collamat® 3600 is connected to the terminal, it must be switched on. At this
moment the DIL-switch TEST must be set to on. The traction unit begins to turn with the
speed set on the SPEED potentiometer. The terminal shows the following message:
COLLAMAT 3600 V1.01
Motor intervall test. Use spacebar to leave
Pressing the spacebar stops the motor intervall test. Now the following help menue will
be displayed:
Helpmenue for C3600 Testprogram
-------------------------------
H : Help
M : Motortest
N : Motor intervall test
B : BUS-signal selftest
S : Signals display
D : DIL-switch settings
P : Potentiometer settings
V : Firmware Version
Select Testfunctions with the Keys H,M,N,B,S,D,P,V
>
The testfunctions can be called with the appropriate keys. All testfunctions can be stop-
ped with the spacebar.
Motortest
The Motortest is used for measuring the phase currents of the motor. The motor turns
with the speed set on the SPEED potentiometer.
>m
Motortest. Use spacebar to leave
Motor intervall test
The Motor intervall test tests the labelling functions of the Collamat® 3600. If a label
web is threaded through the dispenser, labels will be dispensed periodically with the
speed set on the SPEED potentiometer.
>n
Motor intervall test. Use spacebar to leave
5999.527-01A 25.11.98 WM Seite 10 / 32
