Signal display
This test displays the levels of the input signals. It is used to test the function of the sen-
sors and input circuits.
>s
Signals display. Use spacebar to leave
GSC1 READY LSC FAULT
OFF OFF OFF OFF
DIL-switch settings
This test shows the position of the DIL-switches. It is used to test the function of the
DIL-switches.
>d
DIL-switch settings. Use spacebar to leave
TEST DIR
ON OFF
Potentiometer settings
This test shows the position of the potentiometers. It is used to test the function of the
potentiometers.
>p
Potentiometer settings. Use spacebar to leave
SPEED PRE. TCY
0631 0057 0187
Firmware Version
This test displays the firmware version number and its release date.
>v
Firmware Version
COLLAMAT 3600
Version : V1.01
Date : 28. Nov. 1996
