After pressing the ENTER key the following message will be displayed:
New distance is : 157/100 mm
+ : On
- : Off
M : Modify
R : Reset to factory settings
ENTER : Keep
SPACE : Exit
Select function with the keys +,-,M,R,ENTER,SPACE
Now the incremental encoder can be turned on by pressing the + key.
Incremental-Encoder ON
The ENTER key now stores all datas into the EEPROM. This procedure must be confir-
med with the Y key:
Incremental-Encoder setting is ON
Distance between two pulses is: 157/100 mm
Store Data ? Y/N
After pressing the Y key the programming of the incremental encoder is finished.
Updating EEPROM......OK
To reset the programming of the incremental encoder to the factory settings the R key
must be pressed. The following message then is displayed:
>r
Incremental-Encoder setting is OFF
Distance between two pulses is: 100/100 mm
Store Data ? Y/N
Updating EEPROM......OK
Remark:
To use the speed measuring with an incremental encoder, the DIL-s-
witch R must be switched to ON, the encoder also must be program-
med to ON, and the programmed width must match the mechanical step
width.
5999.527-01A 25.11.98 WM Seite 25 / 32
