Now the entered values are displayed and a request to store it in the EEPROM is
asked.
SPEED limits
Upper limit : 20
Lower limit : 10
Store data ? Y/N
Pressing the Y key stores the data. This function will be skipped with the N key. If the
datas are stored the following message will be displayed:
Updating EEPROM......OK
>
After this message the parameter menue will be displayed again. Now choose an other
potentiometer with its appropriate key or quit the function with the SPACE key.
Incremental encoder programming
The function Incremental encoder helps programming the speed measuring with an
incremental encoder. The first invocation of this function displays the following screen:
>i
Incremental-Encoder setting is OFF
Distance between two pulses is: 100/100 mm
+ : ON
- : OFF
M : Modify
R : Reset to factory settings
ENTER : Keep
SPACE : Exit
Select function with the keys +,-,M,R,ENTER,SPACE
The + or - keys are used to switch the speed measuring with an incremental encoder on
or off. After pressing the M key the step width of the encoder can be entered. The R key
resets all values to the factory settings. The ENTER key stores all datas into the
EEPROM.
In the following example (see also page 40) the incremental encoder is programmed to
a step width of 1.57 mm:
>m
Enter new distance (1/100 mm) : 157
The value is entered in 1/100 mm without period and terminated with the ENTER key.
5999.527-01A 25.11.98 WM Seite 24 / 32
