Figure 1.3.1
Figure 1.3.2
B3SE3-3XF1234 is an example of a current VIN. F
or your own personal reference, fill in the VIN in
the space provided below:
1.4 VIN MATRIX
B2S (BC2-S)
B2L (BC2-L)
B3S (BC3-S)
B3L (BC3-L)
B4S (BC4-S)
B4L (BC4-L)
B5S (BC4-S 5200# Cap.)
Digit 1 thru 3 = Abbreviation (Model)
B5L (BC4-L 5200 # Cap.)
E = DC Drive
Digit 4 = Power System
G = AC Drive, Induction Motor
3 = 36V
Digit 5 = System Voltage
4 = 48V (8 – 6V)
- = normal
Digit 6 = VIN Spacer
# = Special Product
3 = 300 Amp
4 = 400 Amp
Digit 7= Controller Amperage
5 = 500 Amp
Y = Rear Hydraulic
X = Front & Rear Hydraulic
W = HD Rear Hydraulic
V = HD F&R Hydraulic
U = M18 Rear Hydraulic
Digit 8 = Axle/Brake System
T = M18 F&R Hydraulic
Digit 9 = Build Year
L = 2012, M = 2013, N = 2014, etc.
Digit 10 Thru 13 - Sequence
1234
BC 2012
1-2
