Columbia Tomberlin E-MERGE E2 LE PLUS 2020 - Vehicle Specification

Page 30
VEHICLE SPECIFICATION
Specifications
2-Passenger
4-Passenger
Dimensions
Length*width*height(mm)
No load
2500*1200*1860
3280*1200*1870
Full load
2500*1200*1840
3280*1200*1850
Dimensions
Length*width*height(in)
No load
98.5*47.28*73.28
129.23*47.28*73.68
Full load
98.5*47.28*72.50
129.23*47.28*72.89
Wheel base(mm)
1630
2450
Wheel base(in)
64.2
96.5
Wheel tread(mm)
Front wheel/rear
980/1060
980/1060
Wheel tread(in)
Front wheel/rear
38.61/41.76
38.61/41.76
Weight without batteries and load(Kg)
360
480
Weight without batteries and load(lb.)
793.8
1058.4
Weight of load(Kg)
Weight of passenger(kg)
2*90=180
4*80=320
Weight of batteries (kg)
240
240
Weight of load(lb.)
Weight of passenger(lb.)
2*198.45=396.9
4*198.45=793.8
Weight of batteries (lb.)
529.2
529.2
Overall weight(kg)
780
1040
Overall weight(lb.)
1719.9
2293.3
Weight on the axles for no
Front axle/rear
222/378
270/450
Weight on the axles for no
Front axle/rear
490/833
595.35/992.25
Weight on the axles for full
Front axle/rear
287/493
400/640
Weight on the axles for full
Front axle/rear
633/1087
882/1411.2
AC motor/( Kw/R.min)
5.0/5000
5.0/5000
AC motor/( Hp/R.min)
6.803/5000
6.803/5000
Controller(A/V)
450/48 or 275/48
450/48 or 275/48
Batteries
Batteries
6V*8 or 8V*6
6V*8 or 8V*6
Capacity(AH@20Hrs)
1800
1800
Maximum speed(km/h)
≤32
≤32
Maximum speed(mile/h)
≤19.9
≤19.9
Approximate drive distance(km)
55-70
55-70
Approximate drive distance(mile)
34-44
34-44
Minimum turning radius(m)
≤3
≤5
Minimum turning radius(ft)
≤9.84
≤16.41
Minimum ground clearance(mm)
≥80
≥80
Minimum ground clearance(in)
≥3.15
≥3.15
Angle of approach for no load (°)
≥35
≥35
Front wheel
alignment (no load)
Camber angle
1
1
Steering axis inclination
12
12
Caster angle
5
5
Toe in(mm)
3-5
5-8
Toe in(in)
0.12-0.20
0.2-0.32
The maximum noise (db.)
≤70
≤70
