COMAC CAL FLOW 38 User Manual

Manual FLOW 38 Page 13 (total 54) COMAC CAL s.r.o.
Diameter
nominal
PN 25
PN 40
DN
Screws
Tightening torque [Nm]
Screw
Tightening torque [Nm]
Rubber
PTFE, PFA,
ETFE,PVDF
Rubber
PTFE, PFA,
ETFE,PVDF
10
4 x M12
15
15
4 x M12
15
15
15
20
20
25
25
20
25
25
25
25
25
25
25
25
25
32
4 x M16
25
35
4 x M16
25
40
40
25
35
35
50
50
35
45
35
60
65
8 x M16
35
46
8 x M16
45
55
80
40
48
45
60
100
8 x M20
40
55
8 x M20
50
75
125
8 x M24
50
110
8 x M24
70
120
150
57
115
75
136
200
12 x M24
68
100
12 x M27
85
145
250
12 x M27
88
120
12 x M30
105
220
300
16 x M27
95
125
16 x M30
115
250
350
16 x M30
115
200
16 x M33
140
-
400
16 x M33
135
255
16 x M36
165
-
500
20 x M33
350
430
20 x M36
-
-
600
20 x M36
600
740
20 x M45
-
-
In case of using a corundum or thermoplastic tube, the same torques apply as in case of using the PTFE
tube according to the given pressure series.
Threaded connection (EN 10226-1):
Diameter
nominal
DN
Process connection
[inch]
Tightening torque
[Nm]
10
3/8”
8
15
½“
10
20
¾“
21
25
1“
31
32
1 ¼“
60
40
1 ½“
80
50
2“
5
65
2 ½“
6
80
3“
15
100
4“
14
If you do not find your size or structure in the Torque Table, it is a special or non-standard design. In
such a case, contact the manufacturer for more detailed information.
