COMAC CAL FLOW 38 User Manual

Manual FLOW 38 Page 47 (total 54) COMAC CAL s.r.o.
Basic sensor sizes
Threaded design
Diameter
nominal
[mm]
Threaded
connection
D
2
Outside
diameter
of sensor
L
3
Building length
of sensor
H
4
Building height
of sensor
Weight of
detached flow
sensor (kg)
H
2
Building height
of comp. meter
Compact
flow meter
weight (kg)
4
½“
70
157
92
4
182
5
6
½“
70
157
92
4
182
5
8
½“
70
157
92
4
182
5
10
3/8 “
70
186
90
4
177
5
15
½“
70
190
90
4
177
5
20
¾“
80
200
95
4
182
5
25
1“
90
200
100
5
187
6
32
1 ¼“
100
228
105
5
192
6
40
1 ½“
116
248
113
6
200
7
50
2“
136
258
123
6
210
7
The Table is for PN25.
