Table with flow ranges for individual DN sizes
Diameter nominal
[mm]
Qmin [m3/h] as per Qmin /Qmax
Qmax [m3/h]
1/60 (0.2 m/s)
1/100 (0.12 m/s)
1/200 (0.06 m/s)
(12 m/s)
DN 4
0.01
—
—
0.6
DN 6
0.02
—
—
1.2
DN 8
0.04
—
—
2.2
DN 10
0.06
0.034
—
3.4
DN 15
0.13
0.076
—
7.6
DN 20
0.24
0.142
0.071
14.2
DN 25
0.35
0.21
0.105
21
DN 32
0.6
0.34
0.17
34
DN 40
0.9
0.54
0.27
54
DN 50
1.4
0.84
0.42
84
DN 65
2.4
1.44
0.72
144
DN 80
3.6
2.2
1.1
220
DN 100
5.6
3.4
1.7
340
DN 125
8.9
5.34
2.67
534
DN 150
13
7.6
3.8
760
DN 200
23
13.5
6.75
1350
DN 250
35
21.1
—
2115
DN 300
51
30
—
3050
DN 350
70
41
—
4150
DN 400
90
54
—
5426
DN 500
141
—
—
8480
DN 600
203
—
—
12200
