COMAC CAL FLOW 38 User Manual

Manual FLOW 38 Page 48 (total 54) COMAC CAL s.r.o.
Sandwich (Inter-flanged) design
Diameter
nominal
[mm]
D
1
Outside diameter
of sensor
L
2
Building length
of sensor
H
3
Building height
of sensor
Weight of
detached flow
sensor (kg)
H
1
Building height
of comp. meter
Compact
flow meter
weight (kg)
10*,15
51
90
110
2
195
3
20
61
90
120
2
205
3
25
71
90
130
3
215
4
32
82
90
140
3
226
4
40
92
110
150
4
236
5
50
107
110
165
4
251
5
65
127
130
185
5
271
6
80
142
130
200
6
286
7
100
168
200
226
7
312
8
125
194
200
253
9
338
10
150
224
200
283
11
368
12
200
284
200
340
14
427
15
The Table is for PN25.
* Process connection is performed through DN 15 flange
