COMAC CAL FLOW 38 User Manual

Manual FLOW 38 Page 49 (total 54) COMAC CAL s.r.o.
Flanged design
Diameter
nominal
[mm]
D
Outside diameter
of flanges
L
1
Building length
of sensor
H
3
Building height
of sensor
Weight of
detached flow
sensor (kg)
H
1
Building height
of comp. meter
Compact
flow meter
weight (kg)
10*,15
The outside
diameter
corresponds to
the required
pressure class and
standards.
200
86
4
173
5
20
200
86
4
173
5
25
200
91
5
178
6
32
200
96
6
183
7
40
200
101
7
188
8
50
200
109
9
196
10
65
200
119
11
206
12
80
200
126
12
213
13
100
250
139
19
226
20
125
250
152
26
239
27
150
300
167
37
254
38
200
350
197
44
284
45
250
450
240
65
327
66
300
500
265
78
352
79
350
550
295
88
382
89
400
600
325
106
412
107
500
600
797
115
892
120
600
600
930
125
1025
132
The Table is up to DN 200 for PN25, DN250 and DN300 for PN16, DN350 to DN600 for PN10.
* Process connection is performed through DN 15 flange
