COMAC CAL FLOW 38 - Page 50

Manual FLOW 38 Page 50 (total 54) COMAC CAL s.r.o.
Food industry design
Diameter
nominal
[mm]
Food grade
connection
CLAMP/Screwed
fitting
D
2
Outside
diameter
of sensor
L
3
Building
length of
CLAMP
L
3
Building
length of food
grade
screwed
fitting
H
4
Building
height of
sensor
Weight of
detached
flow sensor
(kg)
H
2
Building
height of
comp. meter
Compact
flow meter
weight (kg)
10
DN 10
70
180
173
90
4
177
5
15
DN 15
70
175
165
90
4
177
5
20
DN 20
80
175
170
95
4
182
5
25
DN 25
90
175
180
100
5
187
6
32
DN 32
100
175
192
105
5
192
6
40
DN 40
116
203
215
113
6
200
7
50
DN 50
136
211
228
123
7
210
8
65
DN 65
151
upon
upon
131
7
218
8
80
DN 80
177
agreement
agreement
144
8
231
9
The Table is for PN25.
Diameter nominal [mm]
DN 15…DN 20
DN 25…DN 40
DN 50
DN 65
DN 80
Outside dimension of CLAMP [mm]
34
50,5
64
91
106
