ComAp IG-NTC-BB Reference Guide

IGS-NT Combi, SW Version 3.0, ©ComAp – May 2013
IGS-NT-Combi-3.0 Reference Guide.PDF
108
Range [units]
NO, YES [-]
Related FW
3.0
Force value
possible
YES
Description
The setpoint is used to enable/disable the island operation, i.e. supplying the load
while the mains is disconnected.
 Island mode is recognized if the mains breaker is open, e.g. the
feedback input MCB feedback is not active.
 Parallel mode is recognized if the mains breaker is closed, e.g. the
feedback input MCB feedback is active.
If the island mode is recognized and island operation is disabled the controller will
open the generator breaker, cool-down the gen-set and stop it. While this situation
persists the controller behavior is following:
 The gen-set start in AUT mode is blocked, it can be started in MAN mode
only.
 The GCB can't be closed.
 The message OfL StartBlck is present in the alarm list (see the alarm
output OfL StartBlck).
NOTE:
See table with examples in the description of the setpoint MFStart enable.
Setpoint: ParallelEnable
Group
Process Control
Range [units]
NO, YES [-]
Related FW
3.0
Force value
possible
YES
Description
The setpoint is used to enable/disable the parallel operation, i.e. supplying the
load in parallel with the mains.
 Island mode is recognized if the mains breaker is open, e.g. the
feedback input MCB feedback is not active.
 Parallel mode is recognized if the mains breaker is closed, e.g. the
feedback input MCB feedback is active.
If the parallel mode is recognized and parallel operation is disabled the controller
will open the generator breaker, cool-down the gen-set and stop it. While this
situation persists the controller behavior is following:
 The gen-set start in AUT mode is blocked, it can be started in MAN mode
only.
 The GCB can't be closed.
 The message OfL StartBlck is present in the alarm list (see the alarm
