Actual relative reserve - when the relative reserve is higher than this value the last
started gen-set (the gen-set with the highest priority) is stopped. This value
contains the following:
[Nominal power of gen-set which is next to be stopped + ((%LdResStp/100) * Sum
of nominal powers of gen-sets loaded in power management except the one
which is next to be stopped)]/(Sum of nominal powers of gen-sets loaded in power
management).
#%LdResStop is used from the currently selected reserve set.
Value: MinR PWR
Currently active Minimal Running Power level. If the value contains 0 the minimal
running power function is disabled.
Group: Sync/Load ctrl
Value: ActPwrReq
This value contains actual required load level, which is used as the input into the
load regulation loop in the parallel to mains operation.
Value: SpdRegOut
This is the actual voltage on the speed governor output of the controller. In case
the output is switched to PWM mode, the relation is 10V ~ 100% PWM.
Value: Speed request
This value contains the speed control signal expressed in %. This value is used
for digital interfacing (via a communication bus) with ECUs that require the
requested speed in %. The relation between Speed request and SpdRegOut is
