3. For Split Ph:
a. Vg1 = Gen. Ph-Ph voltage L1-L2
b. Vg2 = Gen. Ph-N voltage L2
c. Vg3 = Gen. Ph-N voltage L1
4. For Mono Ph:
a. Vg1 = Gen. Ph-N voltage L1
b. Vg2 = 0
c. Vg3 = 0
The mains voltages are displayed in history analogously.
Hint:
To force history download in LiteEdit (direct, modem or Internet) open History window and select
History | Read history command.
Hint:
The first history record after the controller is switched on, programmed or watchdog reset occurs
contains diagnostic values instead of operational. Some fields in these records seem to have
nonsense values. Do not take these values into account.
Hint:
Some of the controller models doesn´t have RTC. In this case there is no Date column and the Time
column contains information about running hours.
Record structure
Number of historical event
Date of historical event in format DD/MM/YY
Time of historical event in format HH:MM:SS
Generator voltage L1-L2 or *see description above
Generator voltage L2-L3 or *see description above
Generator voltage L3-L1 or *see description above
Mains voltage L1-L2 or *see description above
Mains voltage L2-L3 or *see description above
Mains voltage L3-L2 or *see description above
IL-NT Analog input 1 value ( default Oil pressure)
IL-NT Analog input 2 value ( default Water temperature)
IL-NT Analog input 3 value ( default Fuel Level)
Binary inputs/outputs plug-in module (when IL-NT-BIO8 module is configured)
ECU alarm FailureCode (when ECU is configured)
ECUalarm Failure Mode Identifier (when ECU is configured)
IG-IOM, IGS-PTM Analog input 1 value (when configured IG-IOM, IGS-PTM)
IG-IOM, IGS-PTM Analog input 2 value (when configured IG-IOM, IGS-PTM)
IG-IOM, IGS-PTM Analog input 3 value (when configured IG-IOM, IGS-PTM)
