The output opens, if
 alarm is not active and
 FAULT RESET is pressed
AL Overcurrent
Output closes if the generator
*IDMT over current or
current unbalance or
short current alarm activates.
The output opens, if
Alarm is not active and
FAULT RESET is pressed
AL BatteryFail
Output closes when IL-NT performs reset during start procedure (probably due to weak battery) or
when battery under/over voltage warning appears.
The output opens, if
 alarm is not active and
 FAULT RESET is pressed
AL EarthFault
Output closes when Earth Fault Current is detected (extension module is needed).
The output opens, if
 alarm is not active and
 FAULT RESET is pressed
Hint:
For more details see chapter Earth Fault Measurement
AL Common Wrn
Output closes when any warning alarm appears.
The output opens, if
 No warning alarm is active and
 FAULT RESET is pressed
AL Common Sd
Output closes when any shut-down alarm appears.
The output opens, if
 No Sd alarm is active and
 FAULT RESET is pressed
AL Common BOC
The output closes when any BOC alarm appears.
The output opens, if:
 No BOC alarm is active and
 FAULT RESET is pressed
AL Common Fls
Output closes when any Sensor Fail alarm appears.
The output opens, if
 No warning alarm is active and
 FAULT RESET is pressed
AL AI1 Sd
Output closes if the engine oil pressure (configured to the first analog input) shutdown alarm activates.
The output opens, if
