USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 16
2.5 EQUIPMENT CONSTITUTION
RU consists of the following conponents:
Table 2: RU Constitution
Identifier
Function Discription
Power Supply Unit
(PSU)
Converts the input voltage into stable DC to supply power for other modules.
Optical TX/RX Module
Completes optical signal and RF signal convertion, establish fiber-optic
signal link
PA Module
Amplifies the DL signal.
LNA Module
Amplifies the UL signal, has low noise feature.
Duplexer
Filters out the DL/UL signal
MCU
Control and monitor the operation parameter of RU
Li-ion Battery
Provide power supply to MCU after power failure.
2.6 KIT OF PART
Table 3: MU KOP
Identifier
Function Discription
Qty
Power Cable
4m
1
Ethernet Cable
RJ45, 2m
1
Right Angle Iron
RA-0100DE05-5825
1
Left Angle Iron
RA-0100DE05-5826
1
Table 4: RU KOP
Identifier
Function Discription
Qty
Power Cable
1
Masonry Bolt
M10×110
4
Hex Nut
M10
4
Key
2
Hose Clamps
Φ60-Φ260
2
Mounting rack
2
Plain Washer
Φ10
4
Spring Washer
Φ10
4
Fiber Adapter
DLC-06T-LJ
1
GND Wire
BVR10mm
2
,2m
1
End of Section
