USER MANUAL FOR RA-7E00
ENU STATUS : 1-0-0
Copyright - refer to title page
Page 28
OP
PWR
RUN
ALM
OP
OMT
AC 110V-240V
50/60Hz
ANT
Figure 22: RU Connectors
Table 6: RU Connections
Identifier
Functional Description
AC100V～240V
AC110/220V Power supply interface
Grounding port
ANT
N-F connectors, antenna system connection port
OP
SC/APC optical fiber access port, for downlink and uplink connection
OMT
RJ45 ethernet connector, connects with PC to fulfill local commissioning
