Variants
Variant for using the external unit relay
“C.NC.NO relay activation on
actuator command: 2 sec”
Set dip switches in permanent
mode as shown in figure (Dip
switch 8 ON, Dip switches
1,2,3,4,5,6,7 OFF)
230 V
10A MAX
AC-DC
12V/24V
C
M
LL
O
D
E
T
R
SE
-
SE
+
NC
O
+
VV
-
G
N
D
NO
4681
1621VC
Variant for using a safety lock
12/24V
AC/DC
C
M
LL
O
D
E
T
R
SE
-
SE
+
NC
O
+
VV
-
G
N
D
NO
4681
1621VC
JP1
On C. NO contacts. On C. NC contacts.
Excluded: voltage-free
contact
