20
235 1,2,4,6,7.8 Talk time: 90 sec. (default)
236 3,4,6,7,8 Talk time: 180 sec
237 1,3,4,6,7.8 Self-ignition: enabled (default)
238 2,3,4,6,7.8 Self-ignition: disabled
239 1,2,3,4,6,7,8 Confirmation tone on user call = enabled (default)
240 5,6,7,8 Confirmation tone on user call = disabled
243 1,2,5,6,7.8 Awaiting reset time: 10 sec (default)
244 3,5,6,7,8 Awaiting reset time: 1 sec
208 5,7,8 Enables “Reset wait time” on lock-release command (default)
209 1,5,7,8
Disables “awaiting reset time” on lock-release command (awaiting response time or talk
time will be activated)
249 1,4,5,6,7.8 Call transmission: single (default)
250 2,4,5,6,7.8 Call transmission: triple
System mode
0 Simplebus (default)
255 1,2,3,4,5,6,7.8 Simplebus Top (NO Art. 4681/4)
254 2,3,4,5,6,7,8 Restore default
• The module Art. 4681 / Art. 1621VC operates by default as a main external unit (timed busy signal). To set it as a secondary
external unit (busy signal active for the whole time the riser is in use), set all the selector DIP switches to ON.
• When a call is transmitted from the external unit, if a busy tone is heard instead of the ringtone, this means communication
with another external unit is in progress.
System performance and layouts
For further information of system performance and to view installation layouts, click on the type of system that best meets your
needs:
• Building Kit audio/video system for the creation of audio-video systems for small apartment blocks
