Comelit 4681 - External Unit Installation; Installation Guidelines; Physical Installation Steps; Wiring Art. 4681 & 1621 VC

7
External unit installation
3 4
163 cm
130 cm
40-45 cm
100°
163 cm
130 cm
1 2
2
3
1
1
2
Art. 4681 Art. 1621VC
5
Connect the module support frame to earth.
The camera must not be installed opposite bright light sources, or in places where the filmed subject is
against the light.
In dim environments, we recommend additional lighting is provided.
