Chapter 6 Disassembling Procedure
The following section describes the disassembly and reassembly procedures for the monitor and
its components
Who Should Perform Repairs.
Only qualified service personnel (biomedical engineers or technicians) should open the monitor
housing, remove and replace components or make adjustments. If your medical facility does not
have qualified service personnel, contact COMEN or your local COMEN representative.
Caution High-Voltage – Voltages dangerous to life are present in the instrument when it
is connected to the mains power supply. Do not perform any disassembly procedures (other
than server removal) with power applied to the instrument. Failure to adhere to this warning
could cause serious injury r death.
Tools required
Small flat head screwdriver
Needle Nose Pliers
ESD mat and wrist strap
Cleaning Agent
6.1 Disassemble the rear panel
1. First unscrew all screws in the back panel of the monitor below
