TECHNICAL CHARACTERISTICS AND SPECIFICATIONS
BASIC CLASSIC
3.10 5.12 3.11 5.13 5.15 8.15
ELECTRICAL CONNECTIONS
Power supply 230 V
1~50 Hz
400 V
3~50 Hz
230 V
1~50 Hz
400 V
3~50 Hz
Input (kW - HP) 3,0 - 4,1 5,0 - 6,8 3,0 - 4,1 4,8 - 6,5 7,0 - 9,5
Fuse 16 A 16 A
HYDRAULIC CIRCUIT
Maximum supply water temperature (°C - °F) 60 - 140 60 - 140
Minimum supply water temperature (°C - °F) 5 - 41 5 - 41
Minimum supply water ow rate (l/min - USgpm) 12 - 3,2 14 - 3,7 13 - 3,4 16 - 4,2 18 - 4,8
Maximum supply water pressure (bar - psi) 8 - 116 8 - 116
Maximum priming depth (m - ft)
1,5 - 4,9
0 - 0 (models with inlet water box)
1,5 - 4,9 (models without inlet water box)
Inlet water box NO YES/ NO
PERFORMANCE
Maximum ow rate (l/min - USgpm) 10 - 2,6 12 - 3,2 11 - 2,9 13 - 3,4 15 - 4,0
Nominal ow rate (l/min - USgpm) 8,5 - 2,2 10,5 - 2,8 10,5 - 2,8 12 - 3,2 14 - 3,7
Maximum pressure (bar - psi) 140 - 2030 180 - 2610 120 - 1740 180 - 2610 160 - 2320 200 - 2900
Nominal pressure (bar - psi) 130 - 1885 170 - 2465 110 - 1595 170 - 2465 150 - 2175 190 - 2755
Maximum water outlet temperature (°C - °F) 110 - 230 110 - 230
Maximum reaction force on the spray gun (N) 21 30 24 36 38 45
Sound pressure level - Uncertainty (dB(A)) 78,7 - 0,7
(1)
84,9 - 0,7
(1)
Sound power level (dB(A)) 93
(1)
92
(1)
Operator hand-arm vibration - Uncertainty (m/s
2
) 0,9 - 0,24
(1)
2,0 - 0,24
(1)
PUMP OIL AGIP ROTRA MULTI THT
(2)
AGIP ROTRA MULTI THT
(2)
WEIGHT AND DIMENSIONS
Length x width x height (mm - in) 950 x 620 x 850 - 37,4 x 24,4 x 33,5 950 x 620 x 850 - 37,4 x 24,4 x 33,5
Weight (kg - lb) 115 - 254 120 - 265 125 - 276
Diesel tank (l - USgal) 18 - 4,8 18 - 4,8
Detergent tank (l - USgal) 3,5 - 0,9 3,5 - 0,9
(1)
Measurements in agreement with 60335-2-79.
(2)
Also see the corresponding oils table.
The characteristics and specications are guidelines only. The manufacturer reserves the right to make all modications to the equipment deemed necessary.
