Figure 2-8 View of the bottom of the power supply and the MZ 20K,30K (left), MZ 60K (center) and MZ 80K (right)
BEFORE PERFORMING THE WIRING OF THE POWER SUPPLY, MAKE SURE THAT THE POSITION
AND FUNCTION OF EXTERNAL DISTRIBUTES WILL COMBINE THE INPUT / OUTPUT POWER
SUPPLY WITH A POWER DISTRIBUTION PANEL.
CHECK THAT THE FOREGOING POWER SOURCES ARE ELECTRICALLY DISCONNECTED AND
THEN INSERT YOUR NECESSARY KEY WARNINGS TO PREVENT THEIR INCIDENT INCLUSION SO
THAT THE VOLTAGE DOES NOT APPEAR ON THE CABLES WHEN THE UPS IS POWERED.
2.6.1. Maximum currents of the power supply
The currents for the maximum system power given in the table below, depending on the
power of the system. The given currents are used to select the appropriate protections in the
power, battery and receiver lines as well as the appropriate cable cross-sections. Currents
given at 230 / 400Vac installation.
Table 2-1 Power supply table
Dimensions [mm]
(W x D x H)
