Comfort Bilt HP21 - Getting Started; Getting Familiar with Your Stove

Room Temperature
Sensor
Igniter
(Behind Burn Pot)
Hopper Lid Switch
(Beneath Hopper Fill Lid)
Magnetic Side Panels
Serial # and
Safety Placard
Main Power Switch
(Backup Fuse Included)
Front Door Latch/Handle
(Behind Side Panel)
6
comfortbilt.net
Getting Started
Getting Familiar with your Stove
Removable Ash Pan
Drawer
(Behind Magnetic Flip-down
Door)
Control Panel
Pellet Feed Chute
Burn Pot
Heat Exchange Tubes
Heat Tube
Cleaner/Scraper
Inside the Stove Body:
-Auger System
-Circuit Board
-Combustion Blower
-Convection Blower
-Vacuum Switch
-POF Sensors
-Air Intake Damper
Exhaust Port
Air Intake Port
Data Cable
Glass Airwash Damper
(Behind Front Door)
Adjustable Leveling
Feet
