Notice: Be careful to protect the bottom of the stove and floor surfaces when moving the stove. Bottom
edges of the stove may be sharp and can scratch surfaces.
9
comfortbilt.net
Installation
Floor Protection
It is necessary to install Ember Protection: a type 1 floor protector for this stove.
The floor protector must be non-combustible material, extending beneath the stove with a minimum of 6
inches (152mm) in front of the glass, and 6 inches (152mm) to both sides of the stove.
The stove must be installed on a noncombustible floor, with proper floor protection, or on a masonry hearth.
When a clean out T-vent is installed on the inside of a home, the floor protector must extend 2 inches beyond
the rear of the T-vent.
When stove is vented straight through the wall and the clean out T-vent is on the exterior of the home, the
minimum clearance is 2 inches from the back of the stove to the wall.
6"
6"
6"6"6"
6"
2"
2"
Installation
Notice: Clearances may only be reduced by means approved by the regulatory authority having jurisdiction.
Non-combustible floor protection must extend 2 inches (51mm) beneath the flue pipe of installed horizontal
venting or under the top vent adapter with vertical installation. CANADA REQUIRED, USA
RECOMMENDED.
*This will satisfy safety standards for both USA and Canada
