D SERIES Ceiling Loudspeakers Installation and Operation Manual Page 7
Low impedance / 70V & 100V
transformer tap switch
Grille (shown snapped onto
loudspeaker face)
Figure 2. Component part identification (2 of 2)
Metal safety clip and high-impact mono filament
nylon loops that secure grille to loudspeaker face
Tile support bridge rails
Stabilizing flange on rail
(faces the loudspeaker)
Steel can-locking clamp
(shown retracted)
Bridge rail clip on
C-ring support plate
Seismic safety tabs
Drop-Stop™ installation
assistant tabs
Mounting screw holes on optional face adapter
ring (left) and optional can adapter/trim ring
(right)
Component Identification (continued)
