Table VI - 101 REMOTE Cable Connections
Wire Colour Terminal Number Plug Pin
Number
Shield 1 11
Pink 2 3
White 3 10
Brown 4 2
Violet 5 5
Grey 6 12
Green 7 9
Red 8 8
Yellow 9 7
Black 10 6
Blue 11 4
