Programming
• Remove power from the FDW1000.
• Turn all DIP switches OFF.
• Continue to set Central / Remote (Switch 3), Supervision Relay Mode (Switch 4), Pull-Up Resistor
Mode (Switch 5), and number of EXP101 pairs (Switches 6, 7, and 8) using the following table:
DIP Switch Number DIP Switch Setting
1 – not used during programming OFF
2 – not used during programming OFF
3 – Central / Remote
OFF = Remote unit
ON = Central unit
4 – Supervision Relay
OFF = disables supervision relay – allows Relay Channel 3 to operate as an independent
dry contact closure channel
ON = enables supervision relay – allows Relay Channel 3 to be used to monitor the status
of the optical link
5 – Pull-Up Resistor
OFF = disables pull-up resistor
ON = enables pull-up resistor (for copper paths > 200 ft or when using F/2F Casi Rusco 941)
6, 7, and 8 – Number of EXP101
Pairs
OFF OFF OFF = no expansion modules
OFF OFF ON = one pair of expansion modules
OFF ON OFF = two pairs of expansion modules
OFF ON ON = three pairs of expansion modules
ON OFF OFF = four pairs of expansion modules
ON OFF ON = five pairs of expansion modules
ON ON OFF = six pairs of expansion modules
ON ON ON = seven pairs of expansion modules
• Apply power to the FDW1000. The device is now ready to use.
A common ground connection is critical for proper operation. At each remote location, a common
ground must exist between the reader(s), the FDW1000/R, and any EXP101/Rs. At the central loca-
tion, a common ground must exist between the panel, the FDW1000/C, and any EXP101/Cs.
