Technical product description
A190-930TX_EN_03_ 2009-02-06 15
Technical product description
Summary drawing
Regeneration gas orifice
Filling point Pressure gauge (PI)
On/off-switch Vessel
Power supply Control box
Filter for control gas Solenoid valve block (Y1-Y4)
Drain point
Front view
Check valve V3 Check valve V2
Compressed air outlet Eyebolt
Compressed air inlet
Expansion valve V4
Expansion valve V5
Main inlet valve V1 Muffler
Rear view
