Anchoring the dryer
24 A190-930TX_EN_03_ 2009-02-06
Anchoring the dryer
The upright stand profiles of the dryer are provided with four pre-drilled
anchorage bores.
► Use suitable attachment material to
anchor the dryer to the floor (see
figure).
► In the case of vibrating floors: place the
dryer on suitable vibration dampers.
Bores at the foot of the dryer
Storing the dryer
If the dryer is to be stored for an extended period of time, the storage location
must meet the following conditions:
The dryer must not be stored in the open air.
The storage room must be dry.
The storage room must be free from dust or the dryer must be covered by a
protective sheet.
The storage room must have an ambient temperature of at least +1 °C
(33,8 °F).
In order to store the dryer proceed as follows:
► Take dryer out of operation as described on page 39.
► Ensure that the compressed air inlet valve installed by the owner, and the
installed compressed air outlet valve installed by the owner, are both closed,
and that the dryer is depressurised.
► Disconnect dryer from the compressed air system.
► Disconnect the dryer from the electrical power supply and all external lines.
► Use film material or similar to close the compressed air inlet apertures and
compressed air outlet apertures on the dryer in order to protect them against
contamination.
► If possible cover dryer with a protective sheet.
The dryer can now be stored for long periods.
