Installation
External components
5
6.1. General warnings
The installer should read this instruction manual carefully before
installing the machine. The machine must be installed by quali ed,
authorized staff, respecting the applicable safety and hygiene
guidelines.
6.2. Important warnings
The operator must be a responsible adult and under no cir-
cumstances a minor or a person unable to deal with said respon-
sibility.
When handling the grinder, the following precautions must be
taken into consideration:
• Do not handle with bare feet
• Hands or feet must not be wet
• Do not submerge the machine in water
• Do not expose the machine to sunlight or other atmospheric
conditions
Never insert any object into the coffee input or output
openings when the machine is turned on. (Please bear in mind
that when the grinder stops, the burrs continue to turn for a
few seconds.)
• To disconnect the grinder, always pull out the plug and never
the electrical cable, to avoid the possibility of a short circuit.
i
!
12
11
11
10
10
9
8
7
7
6
5
4
4
3
2
1
Hopper lid
Hopper lid
Coffee bean
Coffee bean
hopper
hopper
Hand protector
Hand protector
Hopper
shutter
Setting roller
Setting roller
Grind regulator
Grind regulator
Dispenser lid
Dispenser lid
Dispenser
Dispenser
regulator
regulator
Ground
coffee dispenser
Dispenser
handle
Tamper
Tamper
Position
indicator &
safety block
13
Support crutch
Support crutch
14
14
On-Off
Switch
15
Coffee
Coffee
collection tray
collection tray
