- 8 -
Headphones jack
Headphones connection for personal listening.
Micro-USB port (not for charging)
Connect to a PC or USB storage device.
USB port
Connects to a USB storage device or a mouse or
a wire keyboard.
Microphone
For voice input.
Mini HDMI port
Connects to a TV or a display device.
DC jack
Connects with 5V DC charger.
Charging indicator
Orange: Charging
Green: Fully charged
Red (blinking): Low battery
POWER button
Press to enter standby/wake up mode, press
and hold to switch On/Off the unit.
Reset
Reset the tablet (then press and hold the POWER
button for 4~5 seconds to turn on the unit).
MicroSD card slot
Accepts microSD card (up to 128GB).
Volume +/- button
Press to increase/decrease the volume.
Left side view
