1-8 Product Description
1.4.4 Rear Panel Connectors - Intel 810/810e
Rear Panel Connectors - Intel 810/810e
Ref. Component Ref. Component
1
Power Cord Connector
8
Headphone Connector
2
Voltage Select Switch (switches
voltage between 115V and 230V to
match geographical requirements)
9
Line-Out Audio Connector
3
Universal Serial Bus (USB)
Connectors (2) (connects the
computer to any USB peripheral
while the computer is operating; is
a fully functional plug and play
connector)
:
Serial Number
4
Serial Connectors
;
Line-In Audio Connector
5
Keyboard Connector*
<
Microphone Connector
6
Mouse Connector*
=
Parallel Port Connector
7
Monitor Connector
*Keyboard and mouse ports are interchangeable
