2-16 Spare Parts
2.6 Miscellaneous Hardware Kit
Miscellaneous Hardware Kit
Miscellaneous Hardware
Description Spare Part Number
Miscellaneous hardware kit. Includes: 166877-001
1 Cover, slot (5 ea.) (101144-001)
2a I/O Panel for 440BX (166802-002)
2b I/O Panel for Intel 810/810e (123556-001)
* I/O Panel for Intel 810e PCA=010697-101 (166808-002)
3 Fan guard (105427-003)
4 Screw, 6/32 pan head x 1/4 inch (4 ea.) (192308-001)
5 Thumbscrew (2 ea.) (440BX) (197436-001)
* Thumbscrew (2 ea.) (Intel 810/810e) (124702-001)
6 Screw, M3 x 0.25 inch (4 ea.) (247348-001)
* Plastite flathead screw (4 ea.) (247481-001)
* Plastic push lock fastener for fan assy (4 ea.) (118663-002)
* Bracket (270886-002), blank, AGP
* Gasket (247347-072)
(for use on 101144-001 slot cover inserted in 7th slot)
* Gasket (304477-037)
(for use on Intel 810 access panel, 137384-001)
*Not shown
