4-8 Removal and Replacement Procedures
4.7 Front Bezel
1. Prepare the computer for disassembly (Section 4.2).
WARNING:
Power is continuous to the system board and power supply even when the power
switch is turned off. To prevent damage to the unit, disconnect the power cord from the power
source or the unit before beginning disassembly procedures.
2. Lay the computer down on its large base for greater stability.
3. Remove the access panel (Section 4.6).
4. Press the two release tabs 1 at the top of the front bezel.
5. Rotate the front bezel away from the chassis 2 to remove it from the unit.
Removing the Front Bezel
✎
When replacing the front bezel, ensure that the bottom hinge points are properly
placed in the chassis before rotating the front bezel back into its original position.
