4-32 Removal and Replacement Procedures
4.16 AGP Graphics Board (440BX)
4.16.1 AGP Graphics Board Removal (440BX)
1. Prepare the computer for disassembly (Section 4.2).
WARNING:
Power is continuous to the system board and power supply even when the power
switch is turned off. To prevent damage to the unit, disconnect the power cord from the power
source or the unit before beginning disassembly procedures.
2. Lay the computer down on its large base for greater stability.
3. Remove the access panel (Section 4.6).
4. Remove the AGP graphics board as you would any other expansion board
(Section 4.13.3).
Removing the RAGE PRO Graphics Board
To install the graphics board, reverse the above procedure.
