System Overview
10 Evo D310 Micro Desktop
System Features
Component Description
Package
Description
1 front-accessible shelf for CD-ROM, DVD-ROM or CD-RW drive.
1 internal shelf for standard 3.5in hard disk drive (one pre-installed).
4 accessory board slots (3 PCI, 1 AGP).
Width: 35.9cm (14.36in.) Height: 13.7cm (5.48in.) Depth: 41cm (16.4in.).
Processor
Intel Pentium 4: 1.7GHz and above (400/533MHz FSB).
Intel Celeron: 1.7GHz and above (400MHz FSB).
System Board:
Chipset
Intel 845G.
Integrated I/O
6 USB 2.0 connectors (2 front, 4 rear), 2 serial ports (1 optional), 1 parallel port, audio (microphone, line in, line
out).
Graphics
Integrated Intel graphics solution.
Optional graphics card:
- ATI Radeon, 7000 32MB
- ATI Radeon, 7500 64MB
Audio
Integrated Analog Devices AD1981A AC’97 SoundMAX CODEC.
LAN
Integrated Intel Pro/100 VE Network Adapter (10 Base-T/100 Base-TX LAN Interface) or 3COM LAN controller.
Mass storage
Choice of hard disk drives:
Ultra ATA/100: 20GB (5400 rpm), 20GB (7200 rpm), 40GB (7200 rpm), 80GB (7200 rpm).
Floppy drive: standard 1.44MB 3.5” (or alternative second hard drive).
CD-ROM drive: 48X IDE.
DVD-ROM drive: 16X, 40X IDE (WinDVD MPEG2 decoding software from InterVideo included).
CD-RW drive: 40X, 10X, 40X IDE (DLA and MyCD software from Veritas included).
Main memory
Two DDR-SDRAM sockets using: 128MB, 256MB and 512MB 266MHz DDR-SDRAM. Maximum of 1GB.
Input devices
Compaq PS/2 keyboard and scrolling mouse.
Power supply
Input Voltage: 100-127V 6A max.
200-240V 4A max ac (voltage selection switch).
Input Frequency: 50/60 Hz.
Connectors
Keyboard, mouse, VGA, parallel, serial, video, 6 x USB (4 rear, 2 front), 1 Ethernet port, 3 x audio (stereo-in,
stereo-out, microphone-in).
BIOS
Based on American Megatrends Inc. (AMI) core 7.00T. BIOS, Version: JH.01.yy. This BIOS is not localized.
