5–26 Maintenance and Service Guide
Removal and Replacement Procedures
5.11 Top Cover
1. Prepare the computer for disassembly (Section 5.3) and
remove the following components:
a. LED cover (Section 5.8)
b. Keyboard and shield (Section 5.9)
c. Display (Section 5.10)
2. Turn the computer bottom side up with the front facing
forward.
Top Cover
Spare Part Number Information
For Dual Point (TouchPad and Point Stick)
For TouchPad only (silver finish for use with
Presario 2800 models)
For TouchPad only (carbon finish for use with
Evo Notebook N800c, N800v, and N800w models)
285256-001
285257-001
295699-001
268135-002.book Page 26 Thursday, October 24, 2002 4:10 PM
