5–42 Maintenance and Service Guide
Removal and Replacement Procedures
5.17 Disk Cell RTC Battery
1. Prepare the computer for disassembly (Section 5.3) and
remove the following components:
a. LED cover (Section 5.8)
b. Keyboard and shield (Section 5.9)
c. Display (Section 5.10)
d. Top cover (Section 5.11)
Disk Cell RTC Battery
Spare Part Number Information
Disk cell RTC battery 198718-001
268135-002.book Page 42 Thursday, October 24, 2002 4:10 PM
