Compaq Evo N800c Series

Removal and Replacement Procedures
Maintenance and Service Guide 5–49
5.19 Modem Cable
✎
The modem cable is included in the Miscellaneous Cable Kit,
spare part number 285268-001.
1. Prepare the computer for disassembly (Section 5.3) and
remove the following components:
a. LED cover (Section 5.8)
b.
Keyboard and shield (Section 5.9)
c. Display (Section 5.10)
d. Top cover (Section 5.11)
e. Fan (Section 5.15)
f. System board (Section 5.18)
2. Turn the system board bottom side up with the rear panel
facing forward.
