5.13 Display Release Assembly
✎
The display release assembly is available with silver finish for
Presario 2800 models and carbon finish for Evo Notebook
N800c, N800v, and N800w models. This assembly is included in
the Miscellaneous Plastics/Hardware Kit, spare part number
285261-001 for Presario 2800 models, and spare part number
286868-001 for Evo Notebook N800c, N800v, and N800w
models.
1. Prepare the computer for disassembly (Section 5.3) and
remove the following components:
a. LED cover (Section 5.8)
b. Keyboard and shield (Section 5.9)
c. Display (Section 5.10)
d. Top cover (Section 5.11)
2. Position the top cover bottom side up with the front facing
forward.
