5–2 Maintenance and Service Guide
Removal and Replacement Procedures
5.1 Serial Number
Report the computer serial number to Compaq when requesting
information or ordering spare parts. The serial number is located
on the bottom of the computer (Figure 5-1).
Figure 5-1. Serial Number Location
5.2 Disassembly Sequence Chart
Use the chart below to determine the section number to be
referenced when removing computer components.
Table 5-1
Disassembly Sequence Chart
Section Description # of Screws Removed
5.3 Preparing the computer for
disassembly
Battery pack 0
268135-002.book Page 2 Thursday, October 24, 2002 4:10 PM
