Compaq Evo N800c Series Maintenance And Service Guide

Removal and Replacement Procedures
Maintenance and Service Guide 5–3
Section Description # of Screws Removed
5.3
(continued)
MultiBay device 0
Hard drive 1 to remove hard drive
2 to separate hard drive
bezel from hard drive
5.4 Computer feet 0
5.5 Memory expansion board 1 loosened
5.6 Mini PCI communications board 1 loosened
5.7 Connector cover 2
5.8 LED cover 2
5.9 Keyboard 2 to remove keyboard
shield
5.10 Display 4
5.11 Top cover 16
5.12 Speaker assembly 0
5.13 Display release assembly 2
5.14 TouchPad 4
5.15 Fan 4 loosened
5.16 Processor 0
5.17 Disk cell RTC battery 0
5.18 System board 5
5.19 Modem cable 0
Table 5-1
Disassembly Sequence Chart (Continued)
