5–38 Maintenance and Service Guide
Removal and Replacement Procedures
5.15 Fan
1. Prepare the computer for disassembly (Section 5.3) and
remove the following components:
a. LED cover (Section 5.8)
b. Keyboard and shield (Section 5.9)
c. Display (Section 5.10)
d. Top cover (Section 5.11)
Fan
Spare Part Number Information
Fan 285267-001
268135-002.book Page 38 Thursday, October 24, 2002 4:10 PM
