6–6 Maintenance and Service Guide
Specifications
Table 6-5
14.1-inch XGA, TFT Display
Dimensions
Height
Width
Diagonal
11.22 in
8.46 in
14.1 in
20.50 mm
21.49 mm
35.81 mm
Number of colors up to 16.8 million
Contrast ratio 150:1
Brightness 120+ nits typical
Pixel resolution
Pitch
Format
Configuration
0.264 × 0.264 mm
1024 × 768
RGB stripe
Backlight Edge lit
Character display 80 × 25
Total power
consumption
4.2 W
268135-002.book Page 6 Thursday, October 24, 2002 4:10 PM
