C–2 Maintenance and Service Guide
Screw Listing
Figure C-1. Phillips M3.0 × 4.0 Screw Location
Table C-1
Phillips M3.0 × 4.0 Screw
Color Qty. Length Thread
Head
Width
Black 3 4.0 mm 3.0 mm 5.0 mm
Where used:
One screw that secures the hard drive to the computer
(documented in Section 5.3)
268135-002.book Page 2 Thursday, October 24, 2002 4:10 PM
