Screw Listing
Maintenance and Service Guide C–9
Figure C-8. Phillips M2.0 × 4.0 Screw Locations
Table C-4
Phillips M2.0 × 4.0 Screw
(Continued)
Color Qty. Length Thread
Head
Width
Gold 13 4.0 mm 2.0 mm 4.0 mm
Where used:
One screw that secures the top cover to the base enclosure in the hard drive
bay (documented in Section 5.11)
268135-002.book Page 9 Thursday, October 24, 2002 4:10 PM
